SPECIFICATIONS (7F-10W)

1. Maximum recommended flow: 10L/min
2. Flow Range: 0.5~10L/min
3. Change in maximum flow at 7kPa: ‹ 0.5L/min
4. Oxygen Concentration: 95.5% ~ 87%
5. Maximum Outlet Pressure: 62kPa ± 4.5kPa (8.99psi ± 0.65psi)
6. Pressure Relief Mechanism Operational at: 250kPa ± 25kPa (36.25psi ± 3.63psi)
7. Noise: ≤60dB(A)
8. Maximum Nebulization Rate: ≥0.2mL/min
9. Power Supply: AC120V ±10%;AC220V ±10%; AC230V ±10%; 50Hz; 60Hz; 1.5 amps (AC220V~240V); 3.0 amps (AC120V)
10. Input Power: 850VA
11. Weight: 33kg
12. Dimension: H44.5cm (17.5") x W37.2cm (14.7") x D68cm (Z6.8")
13. Minimum operating time: 30minutes
14. Altitude: Up to 1828 meters (6000 ft) above sea level without degradation of concentration levels. From 1828 meters (6000 ft) to 4000meters (131Z9 ft) below 90% efficiency.
15. Safety system: Current overload or loose connection, automatic shutdown. Compressor with abnormal high temperature, automatic shutdown. High & low pressure alarm function, automatic shutdown. Compressor error function, automatic shutdown. Low oxygen concentration alarm function.
16. Minimum Operating Time: 30minutes
17. Electric classification: Class II , type BF application part
18. Work system: work continuously.
19. NORMAL OPERATION CONDITIONS: Temperature range: 10°C ~35°C (50°F~95°F); Relative humidity: 30%~75%; Atmosphere pressure: 860hPa~1060hPa (12.47psi ~15.37psi);
    • NOTE: When storage temperature is below 5°C. Please keep the equipment in normal working condition for at least 4 hours before using.
20. Temperature at oxygen outlet: ≤46°C
21. Suggestion: The length of nasal oxygen cannula should be less than 15.2 meters and should not be pinched.
22. Transportation and storage conditions: Temperature range: -20°C ~ +60°C(-68°F ~ +140°F), Relative humidity: 10% ~ 93%, no condensation, Atmosphere pressure: 700hPa ~1060hPa (10.15psi ~15.37psi).

NOTE: Oxygen concentrator should be stored without intense sunlight. No corrosive gas and in a well ventilated room, avoid jolt and inverted recumbent transport.
